EC-STR-1
DEWATERING STRUCTURE
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| EC-STR-2 | SEDIMENT FILTER BAGS | POSSIBLE USE OF SEDIMENT FILTER BAG |
| EC-STR-3C | SILT FENCE WITH WIRE BACKING | SEE STANDARD DRAWING FOR INSTALLATION DETAILS |
| EC-STR-3E | SILT FENCE FABRIC JOINING DETAILS | SEE STANDARD DRAWING FOR INSTALLATION DETAILS |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 203-01 | C.Y. | ROAD & DRAINAGE EXCAVATION (UNCLASSIFIED) | |
| 209-05 | C.Y. | SEDIMENT REMOVAL | |
| 209-10.01 | C.Y. | TEMPORARY DEWATERING STRUCTURE |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 10-26-1992 | 12-18-1995 | 10-26-2000 | 05-27-2001 | 12-18-2002 | 01-22-2003 | 04-01-2008 | 08-01-2012 |
