EC-STR-61
LEVEL SPREADERS
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| EC-STR-27 | TEMPORARY SLOPE DRAIN AND BERM | FOR ADDITIONAL DETAILS AND GENERAL NOTES NOT SHOWN ON DRAWING |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 805-01.69 | EACH | LEVEL SPREADER | |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 02-01-2008 | 08-01-2012 | 03-16-2017 |
