EC-STR-31A
TEMPORARY DIVERSION CHANNEL DESIGN
(Click image to open PDF)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| EC-STR-31 | TEMPORARY DIVERSION CHANNELS | THE TABLES ON THIS DRAWING MAY BE USED TO DESIGN TEMPORARY DIVERSION CHANNELS AS SHOWN ON STANDARD DRAWING EC-STR-31 |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 01-20-2006 | 04-15-2006 | 04-01-2008 |
