D-PB-4
PIPE COLLAR DETAILS
(Click image to open PDF)
Latest Revision Note
01/09/2024 Revised General Note (G)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| D-JBS SERIES | Catch Basins and Manholes → JUNCTION BOXES | FOR JUNCTION BOXES |
| D-PB-1 | STANDARD DETAILS FOR CONCRETE PIPE INSTALLATION | FOR PIPE INSTALLATION STANDARD DETAILS & BEDDING MATERIAL |
| D-PB-2 | STANDARD DETAILS FOR FLEXIBLE PIPE INSTALLATION | FOR PIPE INSTALLATION STANDARD DETAILS & BEDDING MATERIAL |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION |
|---|---|---|
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 07-07-2023 |
This Page Last Updated: June 6, 2025 at 1:11 PM
