RD11-SA-1
SAFETY APPROACH TO UNDERPASSES GRADING DESIGN AND SLOPE PROTECTION
(Click image to open PDF)
Latest Revision Note
07/19/2023 DELETED STANDARD DRAWING (IB 23-11)
Related Standard Drawings
| DRAWING | DESCRIPTION | REMARKS |
|---|---|---|
| S-GR-SERIES | SAFETY DESIGN AND FENCES | IN RARE CASES WHEN A STEEP (GREATER THAN 3:1) FILL SLOPE IS UNAVOIDABLE WITHIN THE SAFETY APPROACH ZONE, A BARRIER WILL BE INDICATED ON PLANS IN ACCORDANCE WITH DESIGN POLICY SET OUT |
Related Item Numbers
| ITEM NO. | U/M | DESCRIPTION | REMARKS |
|---|---|---|---|
| 709-05.05 | TON | MACHINED RIP-RAP (CLASS A-3) | |
Archived Standard Drawings
| DATES OF EACH ARCHIVED DRAWINGS ( THE INITIAL STANDARD DRAWING IS BOLD ) |
|---|
| 01-01-2019 |
